Portable Spectrometer For On Site Material Analysis High Resolution Multi CMOS Detector

  • Portable Spectrometer For On Site Material Analysis High Resolution Multi CMOS Detector
Place of Origin China
Brand Name MORITA
Model Number QR-8
Minimum Order Quantity 1 PC
Packaging Details wooden case
Delivery Time 15 days
Payment Terms T/T
Supply Ability 100 pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Dimensions 42 X 22 X 38 Cm Weight Approximately 25 Kg
Highlight

Multi CMOS Detector portable spectrometer

,

High Resolution portable spectrometer

,

680nm advanced ccd imaging spectrometer
You can tick the products you need and communicate with us in the message board.
Detecting the substrate Iron based, copper based, aluminum based, nickel based, cobalt based, magnesium based, titanium based, zinc based, lead based, etc
detection time Depending on the type of sample, it usually takes around 25 seconds
optical system Pascal Runge Roland circular full spectrum optical system
wavelength range 140-680nm
detector High resolution multi CMOS image sensor
electrode Tungsten jet electrode
analytical gap Sample stage analysis gap: 3.5mm
operation temperature (10-35)℃
storage temperature (0-45)℃
Working humidity 20%-80%
Purity requirements for argon gas 100.00%
Argon inlet pressure 0.5MPa
Argon gas flow site Excitation flow rate of approximately 3.5L/min
light source New adjustable digital light source, high-energy pre combustion technology (HEPS)
discharge frequency 100-1000 Hz
Discharge Current Maximum 380A
Excitation table aperture 13mm
vacuum system not have
Working power supply 220V AC/50/60Hz protective grounded single-phase power supply
Instrument dimensions Host 420 × 220 × 380mm
Instrument weight 25kg
Leave a Message
Detecting the substrate Iron based, copper based, aluminum based, nickel based, cobalt based, magnesium based, titanium based, zinc based, lead based, etc
Product Description

Portable Spectrometer For On-Site Material Analysis High-Resolution Multi-CMOS Detector Fast 25-Second Detection Time QR-8

Product Introduction

The QR-8 Portable Spectrometer is a cutting-edge analytical instrument designed for on-site material testing without laboratory constraints. Featuring a high-resolution multi-CMOS detector, it delivers precise and reliable spectral analysis across a wavelength range of 140–680 nm. With a rapid detection time of just 25 seconds, the QR-8 ensures fast and accurate results for industrial quality control and material verification in the field.

Product Advantages

  1. High-Resolution Multi-CMOS Detector – Provides superior sensitivity and precise spectral analysis.

  2. Portable Design – Lightweight and compact, perfect for on-site applications.

  3. Fast Detection – Delivers accurate results in only 25 seconds.

  4. Stable Performance – Advanced optical system ensures long-term reliability.

  5. Versatile Use – Suitable for a wide range of metals and alloys.

Applications

  • On-Site Testing – Ideal for field inspections where laboratory access is limited.

  • Material Identification – Determines material grades for industrial and research applications.

  • Quality Control – Ensures metal and alloy composition meets required standards.

  • Research & Development – Supports advanced studies in material science.

Technical Specifications

Parameter Specification
Detection Application On-site material testing and grade identification
Detection Time ~25 seconds
Optical System Full-spectrum Pascal-Runge Roland design
Wavelength Range 140–680 nm
Detector High-resolution multi-CMOS image sensor
Electrode Tungsten jet electrode
Analytical Gap 3.5 mm
Operating Temperature 10–35 °C
Storage Temperature 0–45 °C
Working Humidity 20–80%
Power Supply 220 V AC / 50–60 Hz
Dimensions 420 × 220 × 380 mm
Weight 25 kg

Why Choose QR-8?

The QR-8 Portable Spectrometer combines high-resolution detection, fast analysis, and field-ready portability to deliver laboratory-level performance anywhere. Whether for industrial quality control or remote material testing, it ensures accuracy, efficiency, and durability, making it a trusted choice for professionals across multiple industries.
